  • WALBRO Hellcat - 525lph Universal Fuel Pump - Ethanol E85

    $199.00 $147.00

    HELLCAT 525LPH Fuel Pump. The highest output in-tank fuel pump on the market!

    Enjoy the highest output on today’s market with our new DCSS 39/50 fuel pump. Able to support an aggressive 700+ horsepower, with a super charger, this innovative dual pumping channel design delivers maximum pressure with superior fuel flow. Operating in both gas and E85, this fuel pump comes with a check valve to avoid system leak-down and extended cranking at start-up. This superior design results in improved hot fuel flow, as well as minimal noise, increasing efficiency by 20% over conventional pumps, delivering unparalelled performance
    F90000285 Flex Fuel HP Pump The innovative design of the DCSS 39/50 features a single impeller with two parallel rows of turbine blades. Designed for high performance engines exceeding 500hp.

    • Highest flow in-tank brushed fuel pump offering from TI Automotive
    • Featuring award winning DCSS technology
    • E85 compatible
    • Internal check valve — prevent fuel system pressure bleed down — prevent extended cranks
    • High pressure relief setting — support supercharger and turbo applications
    • Capable of supporting 900+HP at 60PSI naturally aspirated applications
    • Flush mountable to existing hanger with installation kit 400-0085

    Fuel: GAS & E85
    Horsepower: 900+ at 60PSI, naturally aspirated applications
    Over All Pump Length: 131mm
    Main Housing Diameter: 39mm
    Lower Housing Diameter: 50mm
    Fuel Inlet Diameter: 11mm OD
    Fuel Outlet Diameter: 11mm OD
    Flow Rate: 470lph @ 40psi (120+ gph)
    Test Voltage: 13.5 Volts
