  • AEM X-Series Wideband UEGO Air/Fuel Ratio Sensor Controller Gauge

    $257.96 $185.73

    X-SERIES WIDEBAND UEGO CONTROLLER FEATURES:

    • X-Series Wideband UEGO AFR Controller Gauge were fastest responding wideband air/fuel ratio controllers in an independent test vs. 17 competitor wideband AFR controllers
    • Includes Bosch 4.9LSU wideband UEGO sensor
    • Factory calibrated resistor does not require free-air calibration, but technology allows for free-air calibration as sensor ages if user desires
    • Compatible with vehicle/system voltages up to 16V
    • 0-5V & RS232 output for data logging and feedback control, AEMnet (CANbus) for data logging and daisy-chaining multiple controllers up to 16 cylinders
    • Can display AFR values in hundredths of %
    • 52mm gauge diameter and slim 0.825” gauge depth
    • Gauge cup depth only .200” deep!
    • Auto dimming feature
    • User configurable display via buttons on the gauge face for changing AFR values, Lambda and O2%, and 3- or 4-digit display
    • Black bezel and black dual faced faceplate included (gauge only, silver bezel/white gauge option sold separately, PN 30-0300-ACC)
    • Locking connectors


    AFR VALUE RANGE BY FUEL TYPES:

    • Display Gasoline values from 8.0:1 to 20.0:1 AFR
    • Display Lambda values from .55 to 2.00
    • 0-5V Output Gasoline values from 8.5:1 to 18.0:1 AFR
    • CANbus Output Gasoline values from 8.0:1 to 20.0:1 AFR
    • CANbus Output Lambda values from .55 to 2.00
    • 0-5V Output Lambda values from .58 to 1.23
    • 0-5V Output E85 values from 5.7:1 to 12.0:1 AFR
    • 0-5V Output Ethanol values from 5.2:1 to 11.0:1 AFR
    • 0-5V Output Methanol values from 3.75:1 to 8.0:1 AFR
