Fore Innovations L2 Fuel System (dual pump) 2011-2017 Ford Mustang GT 5.0

$1,828.00 $1,728.00

Fore Innovations L2 Fuel System (dual pump) 2011-2017 Ford Mustang GT 5.0  (42-522)


Fore Innovations is the most experienced company with application specific aftermarket fuel systems. They understand the design and manufacturing requirements to make the most effective, capable, and reliable fuel systems and components for the aftermarket motorsport industry.


Description:

1200+ rwhp capable return fuel system with simple and effective hose routing. The feed line run the fuel rails in series and terminates with a stainless/ceramic valve F2i fuel pressure regulator.

     INCLUDES:

  • S197C / S550 Fuel Pump Module (dual pump)
  • F2i Fuel Pressure Regulator
  • 2011+ Mustang GT Billet Fuel Rails
  • 88mm Inline Fuel Filter
  • FCV Checkvalve


All fittings, hose, and hardware necessary to complete typical fuel line plumbing

-30 feet fuel line (your choice)

-Qty 10 compression style billet hose ends

-Qty 2, 1.25" fuel rail extensions

-Qty 5, straight AN to o-ring fittings

-Qty 3, billet low profile 90º AN to o-ring fittings

-Qty 2, billet low profile 180º fittings

-Qty 1, low profile o-ring plug

-Qty 10, -8 hose straps with stainless mounting screws

-Qty 2, 1/8 NPT plugs


Vehicle Fitment:

2011+ Mustang GT with OE, Boss 302, or FRPP intake, Whipple, Kenne Bell, Vortech, Procharger superchargers or any turbo system.




FUEL PUMP SPECS:

Walbro GSS342

  • Gasoline or race gas use only. 265lph @ 40psi.
  • aka the "Walbro 255", for gasoline (and race gas) for in-tank applications.
  • Not recommended for methanol or ethanol blends
  • Recommended in domestic vehicles making less than 800 whp on gasoline.
  • Recommended as a primary pump to be used in conjunction with our higher performance secondary pumps. (that operate intermittently)
  • Internal checkvalve for use in staged (or non-staged) fuel systems

F90000267
  • E85 compatible. 430lph @ 40psi. 87psi safety relief for pump protection.
  • aka the "Walbro 450, 465, or 485", compatible with gasoline, race gas, and ethanol blends up to E99, as well as race gas/ethanol blends.
  • Recommended over the F90000274 when the planned system pressure is intended to stay below 80 psi (base + boost pressure).
  • Able to operate up to 87 psi total fuel pressure.
  • Internal checkvalve for use in staged (or non-staged) fuel systems

F90000274
  • E85 compatible. 430lph @ 40psi. High pressure version of F90000267.
  • aka the "high pressure Walbro 450, 465, or 485", compatible with gasoline, race gas, and ethanol blends up to E99, as well as race gas/ethanol blends
  • Recommended over the F90000267 when the planned system pressure is intended to go over 80 psi (base + boost pressure).
  • Able to operate up to 112 psi total fuel pressure.
  • Internal checkvalve for use in staged (or non-staged) fuel systems

F90000285
  • E85 compatible. 470lph @ 40psi. Higher volume version of F90000274.
  • aka the "Walbro 470 or 525" or "Hellcat Pump", compatible with gasoline, race gas, and ethanol blends up to E99, as well as race gas/ethanol blends.
  • Recommended to be used as a secondary pump in conjunction with a F90000274 primary; however, it may be used as a primary pump for demanding applications.
  • Able to operate up to 112 psi total fuel pressure.
  • Internal checkvalve for use in staged (or non-staged) fuel systems
